PN-LA652

Safeguarding Security and Promoting Productivity in Hybrid Meetings

PN-LA652 AQUOS BOARD® Collaboration Display

Bringing advanced professional functionality to enterprise users, the Sharp PN-LA series ensures compliance with the highest IT security standards while providing maximum flexibility. A built-in SDM expansion slot includes a pre-installed Windows® 11 Pro PC featuring an Intel™ Core i5 Tiger Lake CPU. This expands the display's customizable capabilities, enabling safe and seamless integration into corporate IT systems. Users can also benefit from pre-installed functionalities such as the Sharp Meeting Launcher for quick access to favorite apps and VC platforms, FlatFrog Board collaborative whiteboarding software and AirServer™ mirroring software for wireless screen sharing.

Download Brochure
Two people in a modern office using a digital whiteboard with architectural designs.

Features

  • 65" Class (64.5" diagonal) Screen Size
  • Brilliant Ultra-HD (3,840 x 2,160) Direct Lit LCD Display
  • FlatFrog Board Software for Rooms (1 year) - free download
  • 20–Point InGlass™ M5 (IR) touch screen
  • Pre-installed SDM Windows® 11 Pro PC with Intel™ Core i5 Tiger Lake CPU
  • EnergyStar 8.0 Certified
  • Optional PN-ZCMS1 AV Soundbar available
  • 5-Year Limited Warranty
  • 450 cd/m2 Brightness; 1,200:1 Contrast Ratio
  • Built-In 10W per Channel Stereo Audio System
Interactive screen displaying pie chart and text about advertising; camera mounted at the top.

Options

AV Soundbar PN-ZCMS1


All-in-one unified communication soundbar incl. speaker, microphone and camera

Synappx Go


Whether your meeting is with Microsoft Teams, Google Meet, Zoom, or GoToConnect, users can use Synappx Go to promptly start meetings by scanning the QR code or typing in the pairing code. Once started you'll have the ability to easily share cloud documents and control them on the display from your device. For IT Admins, Synappx adds a layer of security with full-screen mode and the ability to limit users access to Windows features (taskbar, desktop icons etc.) and more!

Product Specifications

Display
Panel Technology TFT LCD
Viewable Image Size 65"
Aspect Ratio 16:9
Screen Resolution 3840x2160
Supported Resolutions 640 × 480, 800 × 600, 1024 × 768, 1280 × 960, 1280 × 1024, 1360 × 768, 1440 × 900, 1680 × 1050, 1280 × 720, 1920 × 1080, 3840 × 2160, 4096 x 2160, 720 x 400, 4096 x 2160p, 3840 x 2160p, 1920 x 1080p, 1920 x 1080i, 1280 x 720p, 720 x 576p, 720 x 480p, 640 x 480p, 720(1440) × 576i, 720(1440) × 480i
Module Resolution 3840x2160
Pixel Pitch 0.372 mm
Backlight Type LED Direct-lit
Brightness (typical) 450 cd/m2
Contrast Ratio (typical) 1200:1
Viewing Angle (typical) 178°/178° (CR≧10)
Response Time (Gray to Gray) 8 ms
Refresh Rate 60Hz
Active Screen Area 56.25" x 31.6"
Orientation Landscape/Portrait(counterclockwise)/Face-up 0-20, 45 degrees
Displayable Colors 1.07 billion

Synchronization Range

Horizontal (Analog/Digital) 31.5kHz - 135.0kHz
Vertical 24Hz-70Hz

Input Signal

Video Analog RGB (0.7 Vp-p) [75Ω]
Sync Horizontal/vertical separation (TTL: positive/negative)
PC Signal Compatibility Yes
Macintosh Signal Compatibility Yes
Video Analog RGB (0.7 Vp-p) [75Ω]
Sync Horizontal/vertical separation (TTL: positive/negative)
External Control LAN In/Out and RS232 In - Full external control capabilities
Digital HDMI (2.0 x 2 with HDCP 2.3), USB-C x1, Display Port 1.2 (HDCP compatible) x 1
Audio 3.5mm mini stereo jack
External Control RS-232C, LAN, IR Remote
Data USB (3.2 compliant) (Type A) x 2, USB (3.0 compliant) (Type B) x 1, USB (2.0 compliant) (Type A)
Digital Digital audio output (optical) x 1
Audio 3.5mm-diameter stereo mini jack x 1
On 190W
ECO Mode Standby 0.5W
Network Standby 0.5W
Power Consumption (max) 350W
Power Savings Mode 0.5W
Bezel Width (Left/Right, Top/Bottom) 0.19 in./0.19 in., 0.19 in./1.27 in. : 4.8 mm/4.8 mm, 4.8 mm/32.3 mm
Dimensions(WxHxD) 58.8" x 34.3" x 3.6"
Shipping (WxHxD) 65.3" x 44.4" x 8.85"
Net Weight 108.1 lbs. / 49 kg.
VESA Hole Configuration 600 x 400mm (M8 x 4-hole)
Operating Temperature 41°F to 95°F (5°C to 35°C)
Operating Humidity 20% to 80% (no condensation)

Limited Warranty (Parts & Labor)

5 years

More Information

Additional Features

  • 4K Resolution
  • 4K Ready
  • 60 Hz LED Frame Rate
  • Built-In Speakers
  • LED Backlight
  • Power Management
  • Wired Network Connection
  • LAN control capability
  • Pen-on-paper®
  • Contrast Ratio (1200:1)

Optical

Display Technology TFT LCD

Accessories

Included:

  • AC power cord:1
  • Remote control unit:1
  • Remote control unit battery (AAA size) : 2
  • Setup manual:1
  • Blank sticker(cover SHARP logo):1
  • Cable clamp:3
  • Camera mount:1
  • Camera mount screw:2
  • USB cable:1
  • Touch pen:2

Optional:

  • PN-ZCMS1 AV Soundbar

Third Party

  • Shuttle PN-SPCi7W11A signage PC
  • Shuttle PN-SPCi5W11A signage PC
  • Peerless PN-SR780M Rolling Cart
  • Peerless PN-SR763ACC1 Accessory Shelf
  • Airserver ASC200 Universal Screen Mirror Solution
  • EverPro EP31605SH 5 Meter USB Type C cable

Cooling Method

Fanless - Convection

  • USB Viewer
  • Permits playback (without a PC) of presentations or display images stored as JPG files from a USB flash drive.
  • 4K Resolution
  • Provides the ultimate in screen clarity.
  • Round-The-Clock Scheduler
  • Allows for advanced scheduling of monitor powering up/down, increasing panel lifetime, reducing power consumption and saving the time and expense of finding and purchasing a third-party scheduling solution.
  • Wired Network Connection
  • Integrated RJ45 connection for quick connection to the LAN (10/100 base-T capability).
  • Three HDMI inputs
  • Allows for simultaneous digital connections of high-definition sources.
  • Integrated MultiMedia Player
  • Allows the ability to play video, audio or image files directly off USB.
  • Wireless LAN (Optional)
  • Allows you to transmit images from a PC wirelessly to the projector, eliminating the need for traditional cumbersome cables.
  • Built-In Speakers
  • Enhance the visual experience with superior sound.
  • RS-232C and LAN control capability
  • Permits flexible remote-control capabilities from connected devices.
  • LED Backlight
  • Provides for industry-leading low power consumption and less hazardous materials.
  • Built-In Expansion Slot
  • Allows for seamless integration of current and future accessories and third-party components.

3 Year Coverage

  • ADVEXMX-3Y-17: Advanced Exchange 2 Day Freight Service+
  • ONSTEMX-3Y-17: Onsite 2 Day Freight Service+

4 Year Coverage

  • ADVEXMX-4Y-17: Advanced Exchange 2 Day Freight Extended Warranty 4 Years
  • EXTWRMX-4Y-17: Extended Warranty 4 Years
  • ONSTEMX-4Y-17: Onsite 2 Day Freight Extended Warranty 4 Years
  • ADVEXMX-5Y-17: Advanced Exchange 2 Day Freight Extended Warranty 5 Years
  • EXTWRMX-5Y-17: Extended Warranty 5 Years
  • ONSTEMX-5Y-17: Onsite 2 Day Freight Extended Warranty 5 Years


Note: Extended warranties are not valid in personal residences.
